1407
6. Remove the alternator rotor fixing and washer.
1. Idler gear
2. Shaft
3. Fixing
4. Washer
The rotor magnets are very strong. When fitting the service tools to the rotor the
magnets may 'grab' the service tool, causing injury to the hands or fingers. When
installing the service tools, wear suitable gloves to protect hands and fingers.
7. Locate the spigot from the larger of the two thrust pads supplied with service tool
T3880365 to the crankshaft.
1. Thrust pad
