1408
8. Assemble service tool T3880365 to the threaded centre section of the rotor.
NOTICE
Make sure that the thrust pad does not fall out during assembly of the tool.
9. Hold the outer of the tool to prevent rotation then tighten the draw-bolt in the
centre of the tool to release the taper seating of the rotor from the crankshaft.
1. T3880365 - Alternator Housing Puller
2. Alternator rotor
10. Withdraw the rotor and tool as an assembly and then separate the tool from the
rotor. Collect the Woodruff Key and the tool thrust pad from the crankshaft.
