Triumph Rocket 3 GT 2021 - Page 1451

1411
Perform the following operations:
• Seat - Removal
• Battery - Removal
• Alternator Cover - Removal
NOTICE
If the alternator stator needs to be replaced, the crankshaft position sensor will also be
replaced as they are one assembly.
Note the position of the cable guide for installation
Note the routing of the stator harness for installation.
1. Remove and discard the fixings securing the crankshaft position sensor and the cable
guide to the alternator cover.
1. Fixings
2. Crankshaft position sensor
3. Cable guide
