1426
1. Fit the LF antenna as noted for removal and tighten the fixings to 3 Nm.
1. Fixings
2. LF antenna
3. Harness
4. Mudguard carrier
2. Route the LF antenna harness as noted for removal.
3. Fit the left hand mudguard carrier to the mudguard as noted for removal. Tighten the
fixings to 3 Nm.
4. Secure the rear light to the left hand mudguard carrier. Tighten the fixing to 3 Nm.
1. Rear light fixing
2. Fixings
3. Left hand mudguard carrier
