4. Fit the rear mudguard (see Rear Mudguard - Installation).
5. Fit the passenger seat backrest (see Passenger Seat Backrest - Installation).
Front Low Frequency (LF) Antenna
1. Route the LF antenna electrical connector as noted for removal and connect to the
main harness.
2. Fit the LF antenna as noted for removal and tighten the fixings to 3 Nm.
3. Fit the flyscreen (see Flyscreen - Installation).
1. Fixings
2. Electrical connector
3. LF Antenna
Perform the following operations:
• Battery - Installation
• Seat - Installation
