Components with Multiple Integral Connectors
The illustration shows an example of a component with multiple integral connectors.
The multiple integral connectors can be identified by separated grey shaded areas (as
shown), or by a grey shaded area that is divided into multiple sections by black line(s).
The above example shows an engine ECM with three integral connectors, connectors A,
B and C. The component, connector and pin number references can be interpreted as
follows:
