Components with an Integral Connector
The illustration shows an example of a component with an integral connector.
The component is identified by a white box, with a grey shaded area representing the
integral connector. Information provided with the component includes:
• The component name - located above the component.
• A function reference for each terminal - located inside the component, adjacent
to the connecting wire (provided in English only).
• Wire colour references - located on each wire.
• A component and pin number reference - located on each wire entering the
integral connector.
In the above example, the component and pin number references can be interpreted as
follows:
