The smart key has two modes, active mode and passive mode.
A short press on the smart key button shows the current status of the key. The smart key
LED will flash:
• Green when the key is in active mode.
• Red when the key is in passive mode.
To switch modes, press and hold the smart key button until the LED changes colour from
green to red or vice versa.
In active mode, the smart key must be within (one metre/three feet) of the LF antenna to
allow the motorcycle to be powered on and started. If the smart key is out of range of
the LF antenna then it will be unresponsive and the keyless ignition cannot be activated.
In passive mode (or if the smart key battery is flat) the smart key must be held against
the LF antenna to allow the motorcycle to be powered on and started (see Immobiliser
Components Location).
Passive Key Operation
Passive keys must be held against the LF antenna to allow the motorcycle to be powered
on and started.
Smart Key Battery Replacement
1. Ensure the smart key is turned to its passive mode (red LED).
2. Remove the fixing and remove the battery cover.
3. Noting its orientation, remove the battery.
Installation is the reversal of removal, noting the following.
• A CR2032 battery is required.
• Tighten the fixing to 0.3 Nm.
