Pairing New or Replacement Keys
1. Obtain all available motorcycle keys from the owner.
2. Remove the rider's seat.
3. Power the motorcycle ON using a paired key.
Refer to the following guidelines for advice on which key to use to power the
motorcycle ON:
Guidelines - Replacing a Lost Smart Key
Guidelines - Adding a Second Smart Key
4. Connect the Triumph diagnostic tool.
5. Navigate to CHASSIS DIAGNOSTICS - IMMOBILISER DIAGNOSTICS - Configure.
Before clicking Re-Register All Keys, ensure that you have all keys being paired to
hand.
A ten minute (600 second) security time delay is then initiated for the first key pairing.
Do not leave the motorcycle unattended during this time.
During the ten minute (600 second) time delay, the pairing of the key used to power
the motorcycle ON is retained. It is therefore not necessary to re-pair this key. All other
paired keys are registered as inactive.
After the ten minute (600 second) time delay has elapsed, a pairing command is
transmitted by the Low Frequency (LF) antenna. The Triumph diagnostic tool will
prompt you to position the key being paired against the LF antenna.
The LF antenna is located beneath the underseat storage compartment. For pairing
purposes, the antenna can be accessed from inside the storage compartment. A
symbol is provided inside the storage compartment to identify the antenna location.
Only allow one key to be brought into close proximity of the LF antenna during each
key pairing.
Further keys can be paired by clicking Add. A five minute (300 second) time delay is
applied to each subsequent key pairing.
