Always store spare keys and the key number tag in a safe place away from the
motorcycle.
At least one paired key is required to start any key pairing operations. If all keys have
been lost, it will not possible to pair any replacement keys.
In this situation the keyless ECM and all keys must be replaced.
If the tag bearing the key number is also lost, the lock set (fuel tank cap, seat lock etc.)
must also be replaced.
Pairing the Electronic Steering Lock
There must be at least one key registered before the electronic steering lock can be
paired to the keyless ECM.
1. Remove the rider's seat.
2. Power the motorcycle ON using a paired key.
3. Connect the Triumph diagnostic tool.
4. Navigate to CHASSIS DIAGNOSTICS - IMMOBILISER DIAGNOSTICS - Configure.
Upon clicking Pair, a five minute (300 second) security time delay will be initiated. Do
not leave the motorcycle unattended during this time.
5. Click Pair Electronic Steering Lock. The five minute (300 second) security time delay
will begin.
6. The pairing will completed after the time delay has elapsed. The Triumph diagnostic
tool will report if the pairing has been successful.
