Pairing the Engine ECM
There must be at least one key registered before the engine ECM can be paired to the
keyless ECM.
1. Remove the rider's seat.
2. Power the motorcycle ON using a paired key.
3. Switch the engine Start/Stop switch to the ON (RUN) position.
4. Connect the Triumph diagnostic tool.
5. Navigate to CHASSIS DIAGNOSTICS - IMMOBILISER DIAGNOSTICS - Configure - Pair
ECM and Immobiliser.
The tyre pressure sensor ID numbers may be registered at this point for models fitted
with TPMS.
Upon clicking Pair, a five minute (300 second) security time delay will be initiated. Do
not leave the motorcycle unattended during this time.
6. Models fitted with TPMS only - Enter the front and rear tyre pressure sensor ID
numbers in the spaces provided.
7. Click Pair. The five minute (300 second) security time delay will begin.
8. The pairing will completed after the time delay has elapsed. The Triumph diagnostic
tool will report if the pairing has been successful.
