140
5. Remove the dust cap from the bleed nipple on the slave cylinder.
6. Attach a transparent plastic tube to the bleed nipple.
7. Place the other end of the tube into a suitable receptacle containing new clutch fluid.
8. Clean the reservoir cap before removing.
9. Remove the two fixings for the reservoir cap.
10. Remove the reservoir cap, plastic plate and the diaphragm seal. Check the condition
of the diaphragm seal fitted, replace the diaphragm if necessary.
ا
4. Fixings
5. Reservoir cap
6. Plastic plate 4. Diaphragm seal
7. MAX mark
8. MIN mark
