During bleeding, do not allow the fluid level to fall below the lower level mark in the
reservoir. If the level is allowed to fall below this mark, air may enter the system and
the sequence of bleeding must be repeated.
12. Slowly pull in and release the clutch lever several times until no more bubbles appear
in the tube.
13. When all the air has been expelled from the system, hold in the clutch lever and close
the bleed nipple. Tighten to 5 Nm.
14. Fill the reservoir to the upper level.
15. Replace the reservoir cover and diaphragm ensuring correct fitment of the
diaphragm. Tighten the screws to 1.5 Nm.
16. Remove the transparent bleed tube.
17. Replace the bleed nipple dust cap.
18. Check the clutch for correct operation and fluid leaks. Rectify as necessary.
19. Fit the clutch cover finisher and secure with the single fixing as noted for removal. Do
not fully tighten the fixing at this stage.
1. Fixings
2. Clutch cover finisher
