Triumph Rocket 3 GT 2021 - Page 184

156
12. Turn the camshafts only to allow service tool T3880502 to fit into the camshaft slots.
1. T3880502 - Camshaft timing bar
2. Camshaft slots
13. Check that the camshafts alignment marks on the sprocket end of the camshaft are
pointing inwards.
1. Camshaft alignment marks
2. Exhaust camshaft
3. Inlet camshaft
