Triumph Rocket 3 GT 2021 - Page 185

157
14. Tighten the two accessible (uppermost) camshaft sprocket fixings to 16 Nm.
1. Fixings
15. Remove the wedges between the camshaft sprockets and the crankcase.
16. Remove service tool T3880502 from the camshaft slots.
1. T3880502 Camshaft timing bar
2. Camshaft slots
