Fork Oil Renew – Refilling
The oil level is measured from the upper surface of the fork outer tube, with the fork
fully compressed and the spring and spring spacer removed.
Fork Oil Level (spring, spring seat and spacer removed, and
the fork fully compressed)
Fork Oil Level Chart
upper surface of the fork top cap flange is
55.7 mm above the lower surface of the
upper yoke
Fork Oil Level
1. Fill the fork with the grade of oil specified in the fork oil level chart, to a level above
that which will finally be required.
2. Pump the fork assembly and damper several times to expel any trapped air then fully
compress the fork and support it in an upright position. Leave the fork for a few
minutes to allow the oil to stabilise.
