Triumph Rocket 3 GT 2021 - Page 213

185
Note the original setting of the brake lever adjuster in order that it can be returned to
the same position when the bleeding operation is complete.
12. Turn the brake lever adjuster fully in to give maximum lever span.
1. Brake lever
2. Adjusting screw
Front Brake Fluid
1. Turn the handlebars to bring the fluid reservoir to a level position.
2. Release the fixings and remove the reservoir cap.
1. MIN mark
2. MAX mark
3. Diaphragm seal
4. Reservoir cover
5. Reservoir cap
6. 6. Fixings
