Wear hand, eye and face protection when unhooking the stand spring. Take great
care to minimise the risk of personal injury and loss of components.
2. With the side stand in the up position, unhook the spring from the side stand and
remove it from the motorcycle.
3. Remove and discard the E-clip securing the pivot pin.
4. Remove the pivot pin and remove the side stand.
1. Spring
2. E-clip
3. Pivot pin
Inspection
Inspect the surfaces of the pivot pin, side stand carrier bracket and side stand for
corrosion or damage and replace if required.
