206
Installation
1. Prior to fitting the side stand clean the pivot pin and the bushes in the side stand
with a lint free cloth. Make sure the pivot pin and bushes are free from grease.
2. Fit the side stand to the motorcycle and insert the pivot pin.
3. Fit a new E-clip to secure the pivot pin.
Wear hand, eye and face protection when unhooking the stand spring. Take great care
to minimise the risk of personal injury and loss of components.
4. Hook the spring onto its frame lug then carefully hook it onto the side stand lug.
1. Spring
2. E-clip
3. Pivot pin
5. Check the operation of the side stand before riding the motorcycle. Make sure the
spring holds the stand securely in the retracted position.
