227
12. Carefully withdraw the cover. Discard the gasket
13. Clean the surfaces of the crankcase and the alternator cover using a lint free cloth.
The rotor magnets are very strong. When handling the alternator cover the magnets
may 'grab' the stator, causing injury to the hands or fingers. When handling the
alternator cover wear suitable gloves and only grip the alternator cover by the outside
surfaces; always keep hands and fingers clear when handling the alternator cover.
Alternator Cover – Installation
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
The rotor magnets are very strong. When handling the alternator cover the
magnets may 'grab' the stator, causing injury to the hands or fingers. When
handling the alternator cover wear suitable gloves and only grip the alternator
cover by the outside surfaces; always keep hands and fingers clear when handling
the alternator cover.
1. Thoroughly clean the crankcase, harness grommet and alternator cover mating faces.
2. With the harness grommet detached from the alternator cover, apply two beads of
silicone sealant, 2 mm (+/-0.5 mm), to the alternator cover at the location of the harness
rubber grommet, as shown in the diagram below. Make sure the sealant is a minimum of
2 mm away from any bolt holes. During manufacture ThreeBond 1216E is used.
