Triumph Rocket 3 GT 2021 - Page 257

229
4. Position a new gasket to the crankcase dowels.
5. Fit the alternator cover and tighten the fixings in the following two stages:
Stage 1
6. Tighten the fixings one to twelve in the sequence shown to 10 Nm.
Stage 2
7. Retighten fixings one and two to 10 Nm.
Alternator Cover Tightening Sequence
