241
12. Attach the rear caliper brake line to the ignition coil bracket and secure with a new fir
tree clip.
1. Rear caliper brake line
2. Retaining fir tree clip
3. Fixings
4. Ignition coil bracket
13. Fit the number one cylinder ignition coil to its bracket and tighten the new fixings to
5 Nm.
14. Connect the two wires to the number one cylinder ignition coil as noted for removal.
1. Ignition coil
connections
2. Fixings
3. Number one cylinder
ignition coil
