242
15. Route and connect the high tension cables to the spark plugs as noted for removal.
Perform the following operations:
• Fit the air filter Air Filter - Renew
• Evaporative Canister - Installation
• Fit the left hand Side Panels - Installation
• Fuel Tank - Installation
• Battery - Installation
• Seat - Installation
Clutch Cover – Removal
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
The water pump is an integral part of the clutch cover. If the water pump requires
replacing, a new clutch cover with a water pump must be fitted.
Perform the following operations:
• Seat – Removal
• Battery – Removal
• Coolant Expansion Tank – Removal
• Radiator – Removal
