248
6. Fit the six M6 x 35 mm and five M6 x 50 mm fixings as noted for removal.
1. M6 x 35 mm fixings
2. M6 x 50 mm fixings
3. Radiator lower bracket
7. Tighten the clutch cover fixings in the following three stages:
Stage 1
8. Tighten the fixings one to three in the sequence shown to 10 Nm.
Clutch Cover Tightening Sequence Stage 1
