Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
1. Thoroughly clean the cover and alternator cover mating faces.
2. Make sure the dowels are fitted as noted for removal.
3. Position a new gasket to the alternator cover.
4. Fit the starter drive cover to the alternator cover and tighten the fixings in the
following two stages:
Stage 1
5. Tighten the fixings in the sequence shown to 10 Nm.
Stage 2
6. Retighten fixings one and two to 10 Nm.
Perform the following operations:
• Swinging Arm - Installation
