278
3. Check the alignment marks on the front end of the camshaft journals are pointing
inwards.
1. Camshaft alignment marks
2. Exhaust camshaft
3. Inlet camshaft
4. Check that service toll T3880501 is through the hole in the crankcase.
1. T3880501 - Crankshaft Locking Pin
2. Alignment mark
