279
The plunger of the camshaft drive chain tensioner is under spring tension. Always wear
hand, eye and facial protection when removing the tensioner as unprotected areas of
the body can be injured if the spring tension is released in an unexpected or
uncontrolled way.
NOTICE
If installing a new hydraulic tensioner, do not release the plunger before fitting.
If installing the original hydraulic tensioner, the engine oil must be drained out of the
tensioner to enable the plunger to be set onto the first tooth of the ratchet.
5. Hold the resister ring ends together and pull out the plunger.
1. Resister ring ends
2. Plunger
6. Remove the spring.
1. Spring
