280
7. While holding the resister ring in place, drain the engine oil into a suitable container.
8. Make sure the resister ring is correctly located as shown below.
1. Resister ring
9. Refit the spring.
10. Support the tensioner in a soft jawed vice.
11. Hold the resister ends together, close the vice allowing the plunger to be pushed
through the resister ring until the snap ring aligns with the snap ring groove.
1. Resister ring
2. Plunger
3. Snap ring groove
4. Snap ring
