304
15. Insert service tool T3880501 through the hole in the crankcase. Make sure the gear
tooth on the service tool fits between the two teeth with the alignment marks.
1. T3880501 - Crankshaft Locking Pin
2. Alignment mark
NOTICE
Note the orientation for each camshaft sprockets for installation.
16. Remove and discard the camshaft sprocket fixings.
17. Separate the camshafts from the sprockets.
