308
11. Check the alignment marks on the front end of the camshaft journals are pointing
inwards.
1. Camshaft alignment marks
2. Exhaust camshaft
3. Inlet camshaft
12. Fit service tool service tool T3880502 into the camshaft timing slots.
1. T3880502 - Camshaft timing bar
2. Camshaft slots
