Triumph Rocket 3 GT 2021 - Page 394

366
5. Release the three fixings and remove the slave cylinder from the clutch cover. Make
sure the piston remains in its cylinder. Discard the slave cylinder gasket.
1. Union bolt
2. Sealing washers
3. Fixings
6. If the cylinder is not to be disassembled, retain the piston to the slave cylinder using
a retaining tie such as a rubber band or cable tie.
1. Clutch slave cylinder
2. Retaining tie
