5. Remove the lifter piece and bearing carrier.
1. Lifter piece
2. Bearing carrier
6. Carefully de-stake the clutch centre nut.
7. Remove the centre nut, Belleville washer and a plain washer. Discard the nut and
Belleville washer.
1. Centre nut
2. Belleville washer
3. Washer
