374
8. Remove the clutch centre and pressure plate.
1. Clutch centre and pressure plate assembly
9. Remove the thrust washer from the input shaft.
10. Slide the clutch outer drum assembly gently backwards and forwards to dislodge the
inner bearing. Carefully remove the bearing while supporting the clutch drum.
1. Thrust washer
2. Bearing
3. Outer drum
11. Remove the clutch outer drum.
