385
2. Remove the clutch centre and pressure plate assembly from the outer drum
assembly. Take care not to disturb the friction plate tabs.
3. Position the clutch outer drum assembly to the input shaft.
NOTICE
When the bearing sleeve is correctly fitted, it will be a flush fit with the clutch drum
face.
4. While holding the clutch outer drum in position, refit the bearing and the thrust
washer.
1. Thrust washer
2. Bearing
3. Outer drum
NOTICE
To align the clutch centre splines with the input shaft splines, It may be necessary to
rotate the input shaft.
