387
1. Release plate
2. Chamfer edge
3. Fixing tower
4. Machined face
6. Evenly and progressively tighten the release plate bolts to 10 Nm, ensuring that the
springs remain correctly located and that the release plate is correctly seated to the
pressure plate fixing towers.
7. Fit the original plain washer and a new Belleville washer with its OUT marking facing
outwards.
8. Fit a new centre nut.
1. Centre nut
2. Belleville washer
3. Washer
