388
9. Tighten the centre nut to 160 Nm.
10. Using a suitable pin punch, stake the nut to the shaft.
11. Fit the lifter piece and bearing carrier, ensuring they are correctly installed in the
release plate.
1. Lifter piece
2. Bearing carrier
12. Remove service tool T3880501
1. T3880501 - Crankshaft Locking Pin
2. Alignment mark
