6. Remove the crankshaft scraper.
7. Separate the lower crankcase from the upper crankcase noting the position of the
three location dowels. Make sure that the crankshaft main bearing shells remain in
their original location on the lower crankcase.
1. Dowels
2. Upper crankcase
8. Remove any residual oil and sealant from the mating face of the lower and upper
crankcases using a lint free cloth.
