396
NOTICE
Note the position of the hardened washers under bolts 20 to 27.
5. Progressively release the lower crankcase fixings in the sequence shown below.
Lower Crankcase Release Sequence
Do not use levers to separate the upper and lower sections of the crankcase as
damage to the crankcases could result.
