399
4. Make sure that the three locating dowels are in position in the upper crankcase.
1. Dowels
2. Upper crankcase
5. If fitted, remove service tool T3880504 retain the three fixings for the lower
crankcase.
1. T3880504 - Oil spray jet protectors
2. M6 x 15 mm fixings
3. Oil spray jet
