402
15. In the sequence shown below, tighten the crankcase bolts 1 to 8 to 85° of bolt
rotation using service tool T3880105.
T3880105 - Torque Angle Gauge
Stage 3
16. Tighten the fixings 9 to 27 in the sequence shown to 12 Nm.
Lower Crankcase Tightening Sequence
