405
NOTICE
For the transmission cover there are, six M6 x 30 mm, two M6 x 40 mm, one M6 x 75
mm, one M6 x 90 mm, three M8 x 45 mm and one M8 x 65 mm fixings.
Note that the M8 x 65 mm fixing has a copper washer for installation.
Note the position of the fixings for installation.
1. M6 x 30 mm fixings
2. M6 x 40 mm fixings
3. M6 x 75 mm fixing
4. M6 x 90 mm fixing
5. M8 x 45 mm fixings
6. M8 x 65 mm fixing with a copper washer
1. Remove the oil dipstick from the oil filler tube.
