Triumph Rocket 3 GT 2021 - Page 434

406
2. Progressively release the transmission cover bolts in the sequence shown below.
Transmission Cover Bolts Release Sequence
Do not use levers to separate the upper and lower sections of the crankcase as
damage to the crankcases could result.
NOTICE
Always check that all fixings have been released before attempting to separate
transmission cover from the crankcase.
It is possible that the oil dowel and O-ring for the bearing cap may remain with
transmission cover.
3. Separate the transmission cover from the upper crankcase noting the position of the
two location dowels.
