416
Lower Crankcase
3. Fit the three hollow dowels for the upper crankcase.
4. Fit the solid dowel for the clutch cover.
5. Fit the crankshaft locking pin plug to the crankcase.
6. Fit the four hollow dowels for the sump.
7. Fit the solid dowel for the alternator cover.
8. Fit a new washer and fit the dead shaft clamping plug.
1. Hollow dowels
2. Solid dowel
3. Washer
4. Plug
9. Fit the two solid dowels for the oil pump.
