415
5. Fit the two original solid dowels for the oil tank cover to the transmission cover.
6. Fit the oil filler tube and tighten its fixing to 10 Nm.
1. Solid dowel
2. Fixing
3. Oil filler tube
7. Fit the original crankcase breather hose as noted for removal to the transmission
cover. Secure with its clamp.
1. Fixings
2. Oil spray bar
3. O-ring (oil spray bar)
