Triumph Rocket 3 GT 2021 - Page 475

447
3. Align the two dot alignment marks on the balancer to the protruding rib on the
crankcase.
1. Front balancer
2. Alignment marks
3. Protruding rib
4. Oil pump drive gear
4. While holding the balancer in position, fit the dead shaft.
5. Remove the M6 bolt from the dead shaft.
1. M6 bolt
2. Dead shaft
