448
6. Fit the keeper plate and tighten the new fixing to 10 Nm.
1. Fixing
2. Keeper plate
3. Dead shaft
7. Check that the rear balancer two alignment marks are aligned with the protruding rib
on the crankcase.
1. Rear balancer
2. Alignment marks
3. Protruding rib
