451
4. While holding the balancer in position, fit the dead shaft and clamp assembly.
5. Fit the clamp new fixing and tighten to 10 Nm.
6. Check that the front balancer two alignment marks are aligned with the protruding
rib on the crankcase.
1. Front balancer
2. Alignment marks
3. Protruding rib
4. Oil pump drive gear
NOTICE
If fitting a new rear balancer, continue from step 7.
If fitting the original rear balancer, omit steps 7 to 12
