5. Fit the transmission bearing cap and tighten the fixings in the following two stages:
Stage 1
6. Tighten the fixings 1 to 4 in the sequence shown to 10 Nm.
Stage 2
7. Tighten the fixings 1 to 2 in the sequence shown to 32 Nm.
8. Tighten the fixings 3 to 4 in the sequence shown to 12 Nm.
Transmission Bearing Cap Tightening Sequence
9. Fit the shim(s) between the transmission bearing cap and retaining plate.
