478
10. Secure the output retaining plate to the transmission bearing cap with new fixings
and tighten to 16 Nm.
1. Fixings
11. Fit a new fixing to secure the retaining plate to the upper crankcase and tighten to 16
Nm.
12. Fit the M22 sealing plug and its O-ring to the crankcase and tighten to 40 Nm.
1. M22 sealing plug
2. Torsional damper housing
3. Fixing
