483
1. Make sure the needle roller bearing is fitted to the back of the input shaft.
1. Needle roller bearing
2. Input shaft
2. Carefully fit the input shaft into the crankcase, make sure the back of the input shaft
and needle roller bearing align to its recess in the crankcase.
3. Align the bearing housing as noted for removal, fit the original fixings to the bearing
housing.
4. While supporting the input shaft, evenly and progressively tighten the fixings to fit
the bearing housing and input shaft into the crankcase.
1. Fixings
2. Bearing housing
